Yamaha MONTAGE6 Synthesizer

Unleash your creativity with the Yamaha Montage6 Synthesizer. Combining AWM2 and FM-X sound engines, it delivers unmatched versatility, expressive control, and seamless integration for live and studio performances.


A True In-store Experience
Get expert advice on choosing the right instrument.
Frequently Bought Together



Product Description
The Yamaha Montage6 Synthesizer sets a new standard in dynamic control, sound creation, and streamlined workflow. Powered by Motion Control, a highly programmable control matrix, it enables the creation of deep, expressive, and unique sounds previously unattainable on hardware synthesizers. With the Super Knob, you can achieve dynamic sound changes, while Motion Sequences offer tempo-synchronized, fully customizable control sequences for enhanced sound programming.
The AWM2 engine ensures data compression without compromising sound quality, delivering realistic sound reproduction with 128-note stereo polyphony for rich stereo effects. Integrated Flash Memory supports fast read and write capabilities for your custom samples.
Explore a wide range of incredible sounds, including the Yamaha CFX Premium Grand Piano, detailed strings and woodwinds, and modernized selections from the DX and TX families, all enhanced by the Motion Control Synthesis Engine. Connect seamlessly to your computer via USB and capture every nuance of your creativity in your DAW.
Bundled with Cubase AI, this synthesizer offers integrated recording and editing, making it the perfect choice for stage, studio, and music production.
- 61 FSX Semi-Weighted Keys & Aftertouch
- 5.67GB Waveform-ROM
- AWM2 Sample- & Synthesis-Based Engine
- FM-X Frequency Modulation-Based Engine
- Powerful DSP effects engine for jaw-dropping, fully realized patches
Product Specifications
Dimensions | |
Width | 1,037 mm (40-13/16") |
Height | 131 mm (5-3/16") |
Depth | 396 mm (15-9/16") |
Weight | 15 kg (33 lbs., 1 oz.) |
Control Interface | |
Number of Keys | 61 |
Number of Keys | |
Type | FSX Keyboard |
Initial Touch | Yes |
Aftertouch | Yes |
Tone Generator | |
Tone generator | Motion Control Synthesis Engine AMW2: 8 Elements FM-X: 8 Operators, 88 Algorithms |
Maximum Polyphony | AWM2: 128 (max.; stereo/mono waveforms) FM-X: 128 (max.) |
Multi Timbral Capacity | 16 Parts (internal), Audio Input Parts (A/D*, USB*) *stereo Part |
Wave | Preset: 5.67 GB (when converted to 16 bit linear format), User: 1.75 GB |
Performance | 2707 |
Filter | 18 types |
Effects | Reverb x 12 types, Variation x 88 types, Insertion (A, B) x 88 types*, Master Effect x 26 types *A/D part insertion x 83 types (Preset settings for parameters of each effect type are provided as templates) Master EQ (5 bands), 1st part EQ (3 bands), 2nd p |
Other | |
Controllers | Master Volume, AD Input Gain knob, Pitch Bend wheel, Modulation wheel, Ribbon Controller, Control Sliders x 8, Knobs x 8, Super Knob, Data dial |
Display | 7" TFT Color Wide VGA LCD touch screen |
Connectors | [USB TO DEVICE], [USB TO HOST], MIDI [IN]/[OUT]/[THRU], FOOT CONTROLLER [1]/[2], FOOT SWITCH [ASSIGNABLE]/[SUSTAIN], OUTPUT (BALANCED) [L/MONO]/[R] (6.3 mm, Balanced TRS jacks), ASSIGNABLE OUTPUT (BALANCED) [L]/[R] (6.3 mm, Balanced TRS jacks), [PHONES] ( |
Power Consumption | 27 W |
Accessories | AC Power cord, Owner’s Manual, Cubase AI Download Information |
Live Sets | Preset: 128 and more, User: 2,048 |
Performance Recorder | |
Tracks | 16 Sequence tracks, Tempo track, Scene track |
Recording type | Real time replace, Real time overdub, Real time punch in/out |
Note Capacity | 1 Song/Pattern: Approx. 130,000 notes, Store area: Approx. 520,000 notes (Pattern); approx. 520,000 notes (Song) |
Note Resolution | 480 ppq (parts per quarter note) |
Tempo (BPM) | 5 – 300 |
Arpeggio | Parts: 8 Parts simultaneous (max.), Preset: 10,239 types User: 256 types |
Sequence formats | MONTAGE original format, SMF formats 0, 1 |
Sequencer | |
Patterns | 128 patterns |
Pattern tracks | 16 Sequence tracks |
Pattern Recording type | Real time replace, Real time overdub |
Songs | 128 songs |
Song tracks | 16 Sequence tracks, Tempo track, Scene track |
Song recording type | Real time replace, Real time overdub, Real time punch in/out |
Functions | |
USB audio interface | [Sampling Frequency = 44.1kHz] Input: 6 channels (3 stereo channels),Output: 32 channels (16 stereo channels) [Sampling Frequency = 44.1kHz - 192kHz] Input: 6 channels (3 stereo channels),Output: 8 channels (4 stereo channels) |
